3D CAD - E20

3D CAD for Beginners - Exercise 20

2D Sketch

In this tutorial we'll use the features:

1 Box: Creates a solid box 2 Hole:Hole: Creates a hole based on user-specified values and selections. 3 Circular pattern: Duplicates faces, features, bodies, or components an arranges them in an arc or circular pattern

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
