3D CAD for Beginners - Exercise 22
2D Sketch
In this tutorial we'll use the features:
1.Rib:It adds material of a specified thickness in a specified direction between the contour and an existing.
2.Thin Extrude feature :Extrude a thin wall along selected open or closed profiles.
3.Fillet feature: creates a rounded internal or external face on the part.
4.Extruded cut feature: removes material from the part.
All dimensions are in mm/g/s/ISO
---------------------------------------------------------------------------------------------
