3D CAD - E29

3D CAD for Beginners - Exercise 29

2D Sketch

In this tutorial we'll use the features:

1.Extrude feature: feature will allow you to take a 2D sketch and add thickness to it in the third dimension. 2.Combine: Performs boolean operations between solid bodies. In this tutorial we'll use the extrude feature to make two bodies an combine Them.

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
