3D CAD - E32

3D CAD for Beginners - Exercise 32

2D Sketch

In this tutorial we'll use the features:

1.Extrude feature: feature will allow you to take a 2D sketch and add thickness to it in the third dimension. 2.Extruded cut feature: removes material from the part.

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
