3D CAD - E52-1

3D CAD - Exercise 52 - 1

2D Sketch

In this tutorial we'll use the features:

1. Extrude feature: feature will allow you to take a 2D sketch and add thickness to it in the third dimension. 2. Extruded cut feature: removes material from the part. 3. Coil Feature: create a solid body in the shape of a primitive coil . 4. Fillet feature: creates a rounded internal or external face on the part. 5. Chamfer: The chamfer tool creates a beveled feature on selected edges, faces, or a vertex

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
#Fusion360 #Solidworks #Inventor #Autocad
