3D CAD - E75

 3D CAD - Exercise 75

2D Sketch

In this tutorial we'll use the features:

1.Extrude feature: feature will allow you to take a 2D sketch and add thickness to it in the third dimension.

2.Tread: lets users easily recreate realistic and working threads for their projects

3.Chamfer: The chamfer tool creates a beveled feature on selected edges, faces, or a vertex

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
#Fusion360 #Solidworks #Inventor #Autocad
