3D CAD - E87

 3D CAD - Exercise 87

2D Sketch

In this tutorial we'll use the features:

1 Thin Extrude : Extrude a thin wall along selected open or closed profiles 2 Extrude : add or removes material from the part. 3 Mirror : Creates a copy of a feature, (or multiple features), mirrored about a face or a plane. You can select the feature or you can select the faces that comprise the feature. Select a body in a single model or multibody part to create a mirror entity.

All dimensions are in mm/g/s/ISO ---------------------------------------------------------------------------------------------
#Fusion360 #Solidworks #Inventor #Autocad
